Product Details:
|
| Application: | Making Pipes, Cutting Sheets, Making Small Tools, Making Corrugated Sheets, Making Container, Making Fences | Type: | Steel Coil, Color Coated Steel Sheet |
|---|---|---|---|
| Standard: | BS/EN/GB/AISI | Length: | 6m/12m Or Customized, Customer Request |
| Certificate: | Ce, ISO9001 | Grade: | CARBON STEEL |
| Coating: | AZ41-AZ60 | Tolerance: | ±5% |
| Thickness: | 0.21-0.50mm | Width: | 1000 1250mm Or Customized |
| Hardness: | Full Hard | ||
| High Light: | Zinc Coated PPGL Steel Coil,Z275 PPGL Steel Coil,Pre Painted Aluzinc Steel Coil |
||
| What is Prepainted Aluminized zinc steel? |
Aluminized zinc sheet thick steel plate means that in order to avoid corrosion of the surface of the thick steel plate and increase its service life, the surface of the thick steel plate coat with a layer of metal zinc and aluminum. This kind of galvanized cold-rolled steel sheet is called galvalume.
| Specification of Pre-Painted Gavalume Steel Coils (PPGL) |
| Grade | CGCC,CGCH,G550,DX51D,DX52D,DX53D |
| Thickness | 0.12-4.0mm |
| Width | 600-1500mm |
| Zinc Coating | Z40-600 g/m2 |
| Coating Thickness | Top-15-35, Back 5-15 |
| Color | RAL Color |
| Surface |
Matt,High gloss,Color with two sides,Wrinkle, Wooden color,Marble |
| Paint Brand | Nippon Akzo Nobel Kcc |
| Coil Weight | 2-5tons |
| Coil ID | 508/610 mm |
Prepainted Galvalume Steel Coil/PPGL coating film introduction
Top paint film:
RPE, SMP, HDP,PVDF,Other paints.
Function: It functions as a sunlight proof cover, especially prevent the destroy by the ultraviolet rays. When the top paint film reaches a certain thickness, it forms a compact cover, and reduce the water and oxygen permeability.
Primer paint film:
Polyurethane, Epoxy, PE
Function:Strengthen the adhesiveness between the top paint film and the basemetal. Even permeable water happens, the top paint film will not peel off. There is corrosion inhibitor which is corrosion resistance. Polyurethane is necessary for higher processing flexibility and weather resistance requirements.
Passivation layer
Function:Increase the adhesion between the metallic layer and coating film. Extend life span also.
Metallic coating
Function:The metallic coating provides the fundamental protection for the steel.
The popular coating metal are galvanize, galvalume and other alloyed metals.
Substrate steel
Cold rolled steel is usually used as substrate, it decides the mechanical properties and the steel shape and flatness.
Back paint film
Epoxy, Modified PE.
Back paint can sustain color in good condition and has good binding.
| Prepainted Steel Applications |
PPGL have been extensively used across a wide range of prestigious projects across the world. Typical applications include construction, white goods and automotive industries.
| What is the difference between galvalume and galvanized steel? |
Galvanized steel is made completely of zinc, while galvalume includes aluminum, zinc, and a small amount of silicon. This provides superior durability and resistance to corrosion in comparison to galvanized coating.
| Package & Delivery |
|
Packing |
1.Generally package:Antiwater paper+strapped with min three strapping strips. |
|---|---|
|
2.Standard exporting package. Anti-water paper and plastic+covered by iron sheet+ strapped with min three strapping strips.
|
|
|
3.Excellent package: Anti-water paper and plastic film+ covered by iron sheet+ strapped with min three strapping strips+fixed on
the iron or wooden pallets by strapping strips. |
|
|
Shipping
|
1.Shipping by containers |
|
2.Shipping by bulk ship
|
