Product Details:
|
| Application: | Making Pipes,cutting Sheets,making Small Tools,making Corrugated Sheets...... | Length: | 6m,12m,Customized ,Customers' Request |
|---|---|---|---|
| Grade: | Carbon Steel | Coating: | AZ41-AZ60 |
| Processing Service: | Cutting,Bending,Decoiling,Punching,Welding...... | Width: | 1000mm,1250mm,1200mm,Customized |
| Hardness: | Full Hard | Tolerance: | ±5% |
| Color: | According Customer Request | Surface: | PE Coated |
| Packing: | Standard Seaworthy Packing | ||
| High Light: | Galvalume Color Coated PPGL Steel Coil,12m Prepainted PPGL Steel Coil,Aluminum Zinc Coated PPGL Steel Coil |
||
Shandong Fulilai Steel Group has delivered high-quality, long-lasting pre-painted steel sheet and painted steel coils with a high-grade finish that is uniform in color, gloss, texture and thickness. These durable products combine the strength of steel, the protection against corrosion and the beauty of color into the ideal product for you. Our prepainted steel products are available in a variety of material thicknesses, widths, and lengths as we offer multi-blanking and slitting services.
| What is Prepainted Steel? |
Pre-painted steel is a corrosion resistant substrate that has had paint applied to both sides through a continuous coil coating process, which produces a uniform paint finish. Fulilai Steel Group produces pre-painted steel sheets and coils coils by directly applying primer and paint on to steel sheet in a coating line. The finished products can easily be roll formed, bent, and stamped without tarnishing the paint quality.
| Specification of Pre-Painted Gavalume Steel Coils (PPGL) |
| Products | GI/GL | PPGI/PPGL | CR | Corrugated Steel Sheet |
| Grade | SGCC, CGCC, SPCC, ST01Z, DX51D, A653 | |||
| Standard | JIS G3302 / JIS G3312 / ASTM A653M / A924M 1998 / GBT12754-2006,GB/T9761-1988, GB/T9754-1988, GB/T6739-1996, HG/T3830-2006, HG/T3830-2006, GB/T1732-93, GB/T9286-1998, GB/T1771-1991, GB/T14522-93 |
|||
| Origin | China(Mainland) | |||
| Raw material | SGCC, SPCC, DC51D, SGHC,A653, 201,202,321,301,302,304,304L,316,316L, 310,310S,409,410,430,439,443,445,441 and so on |
|||
| Certificate | ISO9001.ISO14001.OHSAS18001 | |||
| Technique | hot rolled/ cold rolled |
pre-painted, hot rolled /cold rolled |
cold rolled | pre-painted, hot rolled/cold rolled |
| Thickness | 0.12mm-2.0mm | |||
| Width | 30mm-1500mm | |||
| Tolerance | thickness+/-0.01mm | |||
| T Bending (top/back) |
≤ 3T/4T | |||
| Anti-MEK Wiping | 100times | |||
| Zinc coating | ≤275g /m2 | |||
| Color options | RAL Color System or as per buyer’s color sample. | |||
| Type of coating structure |
2/1 or 2/2 coating, or customized |
2/1 or 2/2 coating, or customized |
||
| Coil weight | 3-8MT or as you required |
3-8MT or as you required |
12-13MT or as you required |
3-8MT or as you required |
| Type | Coil or Plate | |||
| Spangle | big / small / no spangle | |||
| Hardness | Soft---full hard | |||
| Supply ability(tons per year/production lines) | 550,000/5 | 450,000/6 | 280,000/4 | 280,000/4 |
| Payment term | T/T; L/C; T/T & L/C | |||
| Price | FOB/CFR/CNF/CIF | |||
| Delivery time |
around 10-15 days after T/T payment or L/C is received. |
|||
| What is aluminum zinc alloy coated steel? |
| Prepainted Galvalume Steel Coil/PPGL coating film introduction |
Top paint film:
RPE, SMP, HDP,PVDF,Other paints.
Function: It functions as a sunlight proof cover, especially prevent the destroy by the ultraviolet rays. When the top paint film reaches a certain thickness, it forms a compact cover, and reduce the water and oxygen permeability.
Primer paint film:
Polyurethane, Epoxy, PE
Function:Strengthen the adhesiveness between the top paint film and the basemetal. Even permeable water happens, the top paint film will not peel off. There is corrosion inhibitor which is corrosion resistance. Polyurethane is necessary for higher processing flexibility and weather resistance requirements.
Passivation layer
Function:Increase the adhesion between the metallic layer and coating film. Extend life span also.
Metallic coating
Function:The metallic coating provides the fundamental protection for the steel.
The popular coating metal are galvanize, galvalume and other alloyed metals.
Substrate steel
Cold rolled steel is usually used as substrate, it decides the mechanical properties and the steel shape and flatness.
Back paint film
Epoxy, Modified PE.
Back paint can sustain color in good condition and has good binding.
| Package & Delivery |
|
Packing |
1.Generally package:Antiwater paper+strapped with min three strapping strips. |
|---|---|
|
2.Standard exporting package. Anti-water paper and plastic+covered by iron sheet+ strapped with min three strapping strips.
|
|
|
3.Excellent package: Anti-water paper and plastic film+ covered by iron sheet+ strapped with min three strapping strips+fixed on
the iron or wooden pallets by strapping strips. |
|
|
Shipping
|
1.Shipping by containers |
|
2.Shipping by bulk ship
|
