304 Stainless Steel Flat, is the most economical stainless flat shape that's ideal for all applications where strength and superior corrosion resistance is required. 304 Stainless Flat has a durable dull, grainy mill finish and is widely used for all types of fabrication projects that are exposed to the elements. Stainless Flats 1/2" thickness and under are sheared and edged, thicker sizes are a true bar. True bar is available on request for thinner sizes. Notice: 1/16" strip flats are sheared from sheet and may have some curvature or twist.
Specifications: ASTM A276, QQS-763, T304/304L, non-polished finish, 1/8" to 1/2" thick is sheared & edged, over 1/2" thick is True Bar (squared edge).
AKA: stainless strip, stainless bar, stainless rectangle
Applications: frame work, braces, supports, plates, marine, food, etc.
Workability: Easy to Weld, Moderate Cutting, Forming and Machining.
Mechanical Properties: Brinell = 170, Tensile = 85,000 +/-,
Yield = 34,000 +/-, Nonmagnetic
How is it Measured? Thickness (A) X Width (B) X Length
Available Stock Sizes: 2ft, 4ft, 6ft, 8ft, 12ft, or Cut to Size
| 304 Stainless Steel Flat Bar Specification |
| What is Stainless Steel Flat Bar |
Stainless steel flat is rectangular and slightly with pure edge of steel stainless steel flat can be semi-finished steel has cold drawn polished stainless steel flat and hot rolled acid white sandblasting stainless steel flat points
Stainless steel flat steel can be composed of a variety of different stress components according to the different needs of the structure, but also can be used as the connection between components widely used in a variety of building structures and engineering structures, such as beams, Bridges, power transmission towers, lifting transport machinery, ships, industrial furnace, reactor container shelves and warehouse shelves
| Applications of 304 Stainless Steel Flat Bar |
Flat bar has a flat surface and rectangular face – making it extremely versatile for a variety of projects. Here are four key uses for flat bar:
1. FRAME CONSTRUCTION
Flat bars are easily cut to length and drilled or welded into place for framework. Because metal bars are durable, and can withhold the construction weight, they are frequently used for this purpose.
2. BUILDING SUPPORT
Flat bar is a basic of building support materials. They are generally used for support braces, ladder hangers, gate latches, duct work, overhead doors, heaters and bracing.
3. IMPROVEMENTS & ADDITIONS
Flat bars aren’t only used during the building stages – they can be used post-construction to reinforce existing structures. Flat bars are easily cut and formed to fit, replace or support materials already in place.
4. INDUSTRIAL ARTWORK
Flat bars are a popular choice for industrial artist and craftsmen who work on large-scale industrial pieces – most notably, statues. Flat bars are malleable to shape and extremely sturdy once forged.
| Available Types SS Flat / Patta / Patti / Flat Bars |
Stainless Steel HR Flat | SS Flat Bar | SS Cold Rolled Patta | SS Hot Rolled Patti | SS Flat Rods | Stainless Steel Patta | SS Patti | SS Machined Cut Flats | Stainless Steel Industrial Patti | ASTM A240 SS Plazma Cut Patta | ASME SA240 Stainless Steel Flat Bar.
