Product Details:
|
| Name: | Stainless Steel Strip | Grade: | 201, 304, 316, 316L, 410, 430, Etc |
|---|---|---|---|
| Standard: | JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc | Thickness: | 0.25 - 3mm |
| Width: | 600mm - 1500mm | Delivery: | 14-21 Days |
| Payment Terms: | 30%TT For Deposit, 70% Balance Before Shipment Or LC At Sight | Hardness: | HV150 - HV600 |
| MOQ: | 2 Tons | Surface: | 2B,BA,HL,BK,NO.1,NO.4,8k,etc |
| High Light: | 410 430 Stainless Steel Strips,HV150 Stainless Steel Strips,ASTM 430 Stainless Steel Strip |
||
ASTM SS 201 202 301 304 304L 309S 316 316L 409L 410S 410 420J2 430 440 Stainless Steel Strips
Stainless Steel Strip
The stainless steel strip is simply an extension of the ultra-thin stainless steel plate. It is mainly a narrow and long steel plate produced to meet the needs of industrialized production of various metal or mechanical products in different industrial sectors.
Cold rolled strip
① Using "stainless steel strip/coil" as raw material, it is rolled into a product by a cold rolling mill at room temperature. Conventional thickness <0.1mm～3mm>, width <100mm～2000mm>;
②["Cold-rolled steel strip/coil"] has the advantages of smooth surface, flat surface, high dimensional accuracy and good mechanical properties. Most of the products are in coils and can be processed into coated steel plates;
③Cold-rolled stainless steel strip/coil production process: ⒈pickling→⒉normal temperature rolling→⒊process lubrication→⒋annealing→⒌flattening→⒍finish cutting→⒎packing→⒏to the customer.
Hot rolled strip
① The hot rolling mill produces strip steel with a thickness of 1.80mm-6.00mm and a width of 50mm-1200mm.
②【Hot-rolled steel strip/sheet】has the advantages of low hardness, easy processing and good ductility.
③Hot-rolled stainless steel strip/coil production process: ⒈pickling→⒉high-temperature rolling→⒊process lubrication→⒋annealing→⒌flattening→⒍finish cutting→⒎packing→⒏to the customer.
The difference
①The strength and yield ratio of the cold-rolled steel strip are good, and the ductility and toughness of the hot-rolled steel strip are good.
②The surface quality, appearance and dimensional accuracy of cold-rolled steel strips are better than those of hot-rolled steel strips.
③ The thickness of cold-rolled steel strip is ultra-thin, and the thickness of hot-rolled steel strip is larger.
Like other materials, the physical properties of stainless steel strip mainly include the following three aspects: thermodynamic properties such as melting point, specific heat capacity, thermal conductivity and linear expansion coefficient, electromagnetic properties such as resistivity, electrical conductivity and magnetic permeability, and Young's modulus of elasticity , stiffness coefficient and other mechanical properties. These properties are generally considered to be inherent properties of stainless steel materials, but are also affected by factors such as temperature, degree of processing and magnetic field strength. Generally speaking, stainless steel has lower thermal conductivity and higher resistance than pure iron, and the properties such as linear expansion coefficient and magnetic permeability vary according to the crystal structure of stainless steel itself.
| Stainless Steel Strip Specifications |
|
Item |
Stainless steel strip |
|
Grade
|
201, 304, 316, 316L, 410, 430, etc
|
|
Standard
|
JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc
|
|
Thickness
|
0.25 - 3mm
|
|
Width
|
600mm - 1500mm
|
|
Length
|
2000/2438/3048mm
|
|
Size
|
1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm, or as required
|
|
Surface
|
2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
|
|
Application
|
Interior/exterior/architectural/bathroom decoration, elevator decoration, hotel decoration, kitchen equipment, ceiling, cabinet, kitchen sink, advertising nameplate
|
|
Lead time
|
7 to 25 working days after the receipt of 30% deposit
|
|
Payment terms
|
30%TT for deposit, 70% balance before shipment or LC at sight
|
|
Packing
|
Wooden pallet or according to customer's request
|
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 201 | .15 Max | 5.5 - 7.5 | 1.00 Max | .060 Max | .030 Max | 16 - 18 | 3.5 -5.5 | .25 Max | |
| 202 | .15 Max | 5.5 - 7.5 | 1.00 Max | .060 Max | .030 Max | 16 - 18 | 3.5 -5.5 | .25 Max | |
| 301 | 0.15 max | 2.00 max | 1.00 max | 0.045 max | 0.030 max | 16-18 | 6–8 | 0.10 | |
| 302 | 0.15 | 2.00 max | 0.75 | 0.05 | 0.03 | 17–19 | - | 8–10 | 0.10 |
| 302B | 0.15 | 2.00 max | 2.0–3.0 | 0.05 | 0.03 | 17–19 | - | 8–10 | - |
| 304 | 0.08 | 2.00 max | 0.75 | 0.05 | 0.03 | 18-20 | - | 8-10.5 | 0.10 |
| 304L | 0.03 | 2.00 max | 0.75 | 0.05 | 0.03 | 18-20 | 6–12 | 0.10 | |
| 304H | 0.04-0.01 | 2.00 max | 0.75 | 0.05 | 0.03 | 18-20 | 8-10.5 | - | |
| 310 | 0.25 | 2.00 max | 1.50 | 0.05 | 0.03 | 24-26 | - | 19-22 | - |
| 310S | 0.08 | 2.00 max | 1.50 | 0.05 | 0.03 | 24-26 | - | 19-22 | - |
| 316 | 0.08 | 2.00 max | 0.75 | 0.05 | 0.03 | 16-15 | 2–3 | 10–14 | 0.10 |
| 316L | 0.03 | 2.00 max | 0.75 | 0.05 | 0.03 | 16-18 | 2–3 | 10–14 | 0.10 |
| 321 | 0.08 | 2.00 max | 0.75 | 0.05 | 0.03 | 17–19 | 9–12 | 0.10 | |
| 410 | .080 -.150 | 1.00 max | 1.00 Max | 0.04 | 0.030 max | 11.5-13.5 | 0.75max |
| Surface Finish | Definition | Application |
| 2B | Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface. | With bright and smooth surface ,easy for further grinding to obtain brighter surface ,suitable for medical instruments ,milk containers ,tableware and so on. |
| BA | Bright heat treatment after cold rolling. | Structual members .etc.kitchen utensil ,cutlery ,eleltric applicances ,medical instruments ,building decorations ,etc. |
| NO.3/NO.4 | Polished with No.150-240 abrasives. | Milky food processing equipment , medicalinstruments ,building decorations. |
| HL | Finshed by polishing with abrasives of suitable grain size to obtain continuous streaks. | Building decorations ,such as elevators ,escalators ,door etc. |
| 6K/8K | A mirror-like reflective surface ,which is obtained by polishing with successively finer abrasives and buffing extensively with all gritlines are removed. | Buliding entrances,bulkding column casting ,elevator's wall doors ,counters,sculptures etc. |
| Stainless Steel Strip Applications |
|
Stainless Steel Strip Processing |
The majority of normal processing can be performed on 201 Stainless Steel Strip Fulilai Steel Group Offers Following Processing for Stainless Steel Strip:
|
Packaging |
We pack our goods in numerous ways based on the products, such as:--
• Boxes and Crates
• Shrink-wrapped
• Carton boxes
• Wooden pallets
• Wooden boxes
• Wooden crates
