DX51D DX52D SGCC Galvalume Steel Coil Hot Dipped Aluzinc AZ150 Garner Red For Roofing

DX51D DX52D SGCC Galvalume Steel Coil Hot Dipped Aluzinc AZ150 Garner Red For Roofing

SGCC Galvalume Steel Coil

Garner Red Galvalume Steel Coil

Galvalume Roofing Sheet

Place of Origin:

China

Brand Name:

TALAT

Contact Us

Request A Quote
Product Details
Name:
Galvalume Steel Coil
Thickness:
0.12-4.0mm
Width:
600-1500 Mm, 20mm-1500mm
Tolerance:
±5%
Standard:
ASTM, JIS, EN, BS, DIN
Surface:
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
Processing Service:
Decoiling, Cutting, Punching
Hard:
Soft, Hard, Half Hard, Quarter Hard, Spring Hard Etc.
Spangle Type:
Regular Spangle
Form:
Coils, Strip Etc.
Technique:
Cold Rolled
Special Use:
High-strength Steel Plate
Application:
Bolier Plate And Construction Material
Payment:
T/T 30% Advanced, Balance Against BL Copy
Price Term:
FOB CIF EXW
Packing:
Standard Seaworthy Packaging
Delivery:
10-15 Days
Payment & Shipping Terms
Minimum Order Quantity
5 tons
Price
Negotiable
Packaging Details
Sea-worthy Package
Delivery Time
10-15 days
Payment Terms
L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability
50000 Tons per Month
Product Description

Hot Dipped DX51D DX52D SGCC Garner red Galvalume Steel Coils Aluzinc AZ150 For Roofing Sheets Material








 What is Galvalume Steel?

Galvalume steel is carbon steel coated with an aluminum-zinc alloy using a continuous hot-dip process, combining the corrosion protection and high-temperature resistance of aluminum with the formability and galvanic protection of zinc.

The galvalume coating is an alloy consisting of approximately 55% aluminum, 43.4% zinc and 1.5% silicon by weight, which is applied to steel by the continuous hot dip process. Galvalume steel sheet offers the best qualities of aluminum coated (aluminized) and zinc coated steel sheet (galvanized). The aluminum/zinc coating has barrier corrosion resistance and heat resistance similar to aluminum coated steel. It also has good bare edge galvanic protection and forming qualities similar to continuously annealed commercial quality galvanized. The appearance of Galvalume coating is quite distinctive. Its smooth, flat and fine spangle and a silvery metallic appearance make it attractive in unpainted applications.

Galvalume Steel Coil is an ideal roofing material because of its strength, extraordinary outdoor corrosion resistance and longevity. Galvalume is offered in both bare and pre-painted versions.

DX51D DX52D SGCC Galvalume Steel Coil Hot Dipped Aluzinc AZ150 Garner Red For Roofing 0



 Specification of Galvalume Steel Coils



Name Galvalume Steel Coil/sheet
Thickness
0.13-3.0mm
Width
Galvalume steel strip:24-600 mm; galvalume steel coil:600-1250mm
Coil weight
Usually is 2-4.5 tons,the max coil is 10 tons
Al Zn coating:
AZ30 ~ AZ160
Coil ID
508 mm/610mm
Sted grade
DX51D,DX52D, ,S350GD,S5S0GD,SGHC
Surface Finish
Small Spangle, Regular Spangle and Big Spangle (Various colors available Green, Blue, Red)
Surface treatment  Chromated / Unchromated Treatment, Oiled or Resin Coated (Anti Finger Print), Dry
Edge Condition Treatment, Oiled or Resin Coated (Anti Finger Print and Non Anti Finger Print)
Packaging
Seaworthy export standard package, or according to the customers requirement
Delivery time
With 15 -25 days after receipt of deposit or L/C
Market
North/South America, Europe, Asia,Africa,Mid East
Productivity
4000 Metric ton /month





 Galvalume Steel Coil Applications





Unique protective characteristics and affordability make the galvalume steel coil and sheet ideal for an extensive range of uses including but not limited to:

  • Residential and Commercial Exterior Building Products
  • Roofing
  • Siding
  • Cabinetry

DX51D DX52D SGCC Galvalume Steel Coil Hot Dipped Aluzinc AZ150 Garner Red For Roofing 1
